22×20 Vertical Roof Metal Garage

No reviews yet

22×20 Vertical Roof Metal Garage

No reviews yet
Price $5,691.00
Deposit to Order

This affordable 22x20 metal building is made in the USA with American steel. With 440 square feet of storage space, it can be used as a 2-car garage, storage building, shop, or large shed.

Customize the height, doors, windows, and colors below to see exactly how much this 22x20 metal garage building costs with the options you need. We offer free delivery and installation instead of a kit.

Customize Your Product

The leg height fully enclosed for the 12 to 24 wide metal garage pages is standard with 9′ legs and can be made taller up to 14′ tall fully enclosed on the regular style and up to 16′ tall fully enclosed on the boxed and vertical style metal garages. (12′ wide can only be made 12′ tall as the structure can not be taller than it is wide). If you are looking for the center height clearance you can type in “center height clearance” in the ask a question on the bottom right of the page or you can always call or email with any questions. The 32 to 60 wide metal garages come standard with 8′ legs fully enclosed and those sizes are available up to 20′ tall.

14 Gauge is the standard tubing used on the framing of the metal buildings, it is 2 1/2″ square tubing.

The optional thicker 12 gauge tubing is 2 1/4″ square tubing.

Framing on the 12 gauge tubing come with a 20 year rust through warranty.

The metal carports & metal garages come standard with 29 GA galvanized steel sheet metal. 26 GA galvanized steel sheet metal, which is a thicker option, is available as an upgrade for an additional fee.

Select the type of level surface you will provide. The level surface must be provided by the customer and we will install and anchor to the selected surface. The site must be level or no more than 3 to 4 inches off level.

Alan’s Factory Outlet metal carports and metal garages come standard Certified 140 mph & 35 psf. The certified carports and metal buildings comes with blue print drawings which are rated for 140 mph wind and 35 psf snow load.

The drawings are usually emailed to you upon your request within approximately 2 to 3 business days after you review and approve and sign your order.

$5,691.00 Price
Deposit to Order

FREE Delivery and Installation Learn More
Price details
$5,420.00 Item Base
Manufacturer Fees The 10% Manufacturer Surcharge is being added to each and every structure, in an effort to account for an increase in steel costs. 3% additional manufacturer surcharge on all orders over $60,000 pretax.
Deposit to Order

Please enter you zip code to make sure we service your location.

Sorry, we don’t deliver to the selected zip code.

Qty:

Only Pay a 10% - 17% Deposit

Product Description Specifications

The 22×20 vertical style metal garage comes standard with 9′ legs fully enclosed. The cost of the garage door, walk in door or window is not included in the price.

Select the garage door size that works best for you and the price with the garage door will automatically be updated in the price with options. Other options such as walk in door, window and taller side height can be added for an additional cost.

Alan’s Factory Outlet 22×20 vertical roof metal garage is 22’ wide by 20’ long and has 440 square feet of fully enclosed storage space.  Please feel free to call a customer service representative today at 1-800-488-6903 with any questions about the carports.

The steel garage shown here include free delivery and installation in Alabama, Arkansas, Georgia, Indiana, Kentucky, Kansas, Louisiana, Maryland, Missouri, Mississippi, North Carolina, Ohio, Oklahoma, Pennsylvania, South Carolina, Tennessee, Texas, Virginia and West Virginia. Delivery area may not be available in all locations.

*The metal garages are subject to change without notice

Upon ordering the metal building at Alan’s Factory Outlet a 10% to 17% deposit is due with either credit card or you can mail a check for the deposit with balance due once the steel garage is delivered and installed and final payment can be given via credit card or check for the remaining balance. Once you order you will be contacted and copy of the order will be emailed to you for you to review and approve to make sure everything is just like you want it.

We anchor the metal garage to the ground with rebar and mobile home anchors or asphalt with rebar and to the cement for free with concrete anchor bolts. The location for the steel garage must be level or within at least 3″ level or less or we will not be able to install it.

22x20 metal garage

Here is a metal garage with two optional garage doors.

The metal garages come certified for 140 mph and 35 psf. To achieve this rating, the metal building will have a tighter screw pattern and be anchored to support the 140 mph wind rating. Generic blue print drawings, which may or may not be required to secure your permit can be emailed to you upon your request within approximately 3 to 4 business days after ordering.

The metal tubing on the metal garage for sale come with 14 ga tubing which is 2 1/2″ by 2 1/2″ square tubing or you can upgrade to the 12 ga tubing which comes 2 1/4″ by 2 1/4″ tubing. The framing on the optional thicker 12 gauge tubing comes with a 20 year rust through warranty.

The steel buildings are custom built in the size, style and with the options you want. You get to choose between 16 different colors for the roof and trim colors. And if you close the sides or ends you also get to pick which color you want it to be.

22x20 metal garage colors

The metal colors on the metal buildings are approximate and may vary.

vertical roof metal garage

What makes the vertical roof metal garages unique is that the metal sheeting on the roof go up and down to help the snow and rain slide off of it.

22x20 metal garage inside view

The vertical metal garage is the strongest style of metal garages because in order to attach the metal sheeting to the roof we have to put cross bracing to attach it so by doing this it makes it the strongest style metal building we have.

You can buy your metal garage online or you can order it by calling Alan’s Factory Outlet toll free at 1-800-488-6903.

Cars2 Cars
Roof StyleVertical
Width22
Length20
SQFT440
Frame14 Gauge
Doors0
Windows0
